Module Voltage Limits
Max Voltage: 49.2V
Nominal Voltage: 44.4V
Min Voltage: 32.4V
Peak Current: 350A
MODULE SPECIFICATIONS
Number of cells | 12 |
Construction | 12 in-series |
Length/Total Length | 14.25"/16.125" |
Width | 12.25″ |
Height | 6" |
Weight | 54 lbs |
Output terminal | Custom |
Amp Hour | 63 Ah |
Total Voltage | 48V |
CELL SPECIFICATIONS
Cell Type | Laminate type |
Cathode material | LiMn2O4 with LiNiO2 |
Anode material | Graphite |
Rated capacity (0.3C)/td> | 63 Ah |
Average voltage | 3.7VDC |
Maximum Voltage | 4.1VDC |
Minimum Voltage | 2.7VDC |
Output terminal | Custom |
Amp Hour | 63 Ah |
Total Voltage | 48V |
